APLUS wheelchair lifts are suitable for solving disabled passengers with large height differences between floors. Platform space can accommodate both wheelchairs and escorts.
APLUS wheelchair lifts are customized products for lifting cargo or wheelchair for disabled people.
APLUS wheelchair lifts have the features of smooth running speed, high safety , easy installation. small space required & no pits required.
APLUS wheelchair lifts are customized products for lifting cargo or wheelchair for disabled people. APLUS wheelchair lifts have the features of smooth running speed, high safety , easy installation. small space required & no pits required.APLUS wheelchair lifts are suitable for solving disabled passengers with large height differences between floors. Platform space can accommodate both wheelchairs and escorts.
Application: APLUS wheelchair lifts are widely used in residential areas, villas, hotels, administrative office buildings, subways, banks, gymnasiums, hospitals and other places of old-age care.
If you’re looking to reduce your utility bills, a wheelchair lift is the perfect fit at home as well as at work because of its energy efficiency. It operates smoothly and quietly so it will not disturb residents at home or workers in the office. What’s more, because no pit is required, installing this lift at your premises will be an easy retrofit job.
APLUS wheelchair lifts are designed to provide easy access for the physically challenged. APLUS wheelchair lifts provide the best architectural choice for commercial applications such as schools, churches and office buildings.
| Wheelchair Lifts | |
| Power | Customized |
| Bottom size | Customized |
| Height | 60mm (from ground) |
| Max height | 9000mm(from ground) |
| Up speed | 70mm/s |
| Max load | 250kg |
| Out size | customized |
| Installation | Install it in the foor |
| Way in and out | 90°or 180° |
| External control | The outer call button is installed on the wall of the stop-and-down site |
| Anti-fall device | Mechanical rope self-locking |
| Drive mode | Steel cable indirect hydraulic method (fork type) |
| Control supply voltage | 24V/DC |
| Motor power | 2.2kw 220V/AC |
| Lift control | one-touch control belt number display |
| Over load protection | Over-current relay control |
| Working condition | Inner door |
| Safety door | Lifting platform off station, safety door manual or automatic locking, to station manual or automatic locking and delay closing |
| Pressure explosion-proof | The hydraulic cylinder carries an explosion-proof valve and controls the speed of the decline in the event of a failure |
| Emergency stop | Press the emergency press switch to control the rise or fall of the machine |
| Manual | The electric valve discharge drops |
| Safety net | When the lifting soleplate drops, the safety net stops running immediately when it encounters an obstacle |
